specifications
Apogee Duet 3
Apogee Duet 3 – PRO MOBILE STUDIO From the tour bus to hotel, never let an idea go to waste with Duet 3. With two inputs and four outputs of top-quality conversion, plus two world-class preamps, Duet 3 is the perfect mobile companion to write and produce your next hit single.
- Pristine A/D and D/A Conversion
- 2 Studio-Quality Preamps
- Zero Latency Monitoring
- iOS, Mac, & Windows Compatible
Focus, right.
It’s time to upgrade your interface to match the quality of your music. Keep your artistry in focus, not the sound of poor quality converters.
Record Like The Pro’s
Just like blackbear, Metro Boomin, and Azelia Banks — you can write, record, and mix your next Grammy-award winning hit with just one device.
Become Part of the Legacy
The Duet shattered expectations of what a home recording studio could sound like. Record at home without dropping all your cash at a big studio.
Give Your Computer a Break
Harness the power of the Duet’s onboard DSP to enhance your recording with Apogee plugins. Add some bite, EQ, or compression to your signal.
Specifications
MIC PRE
- Gain: Up to 65dB
- EIN: 128dB (un-weighted) @ 60dB, 150 Ohm input
- Max Input Level: +18dBu
- Input Impedance: 4k Ohm
HI-Z
- Max input level: 14dBu
- Input Impedance: 3.2kOhm (Pad on), 1MOhm (Pad off)
A/D CONVERSION
- Max input level +4dBu: +18dBu
- Max input level (-10dBV ref): +6dBV
- Input impedance: 6.4KOhm
- Freq resp 20 Hz -20Khz: > +/-0.2dB (@44.1Khz)
- Rel. THD + N: -101dB
- Dyn. Range: 122dB (A-weighted)
D/A CONVERSION
- Max output level (+4dBu ref): +18dBu
- Max output level (-10dBV ref): +6 dBu
- Line output impedance: 50 Ohm
- Freq resp 20Hz -20 Khz: > +/- 0.05dB
- Rel. THD+N : -110dB
- Dyn Range: 125dB (A-weighted)
HEADPHONE OUT
- Max output level headphones: +18dBu
- Headphone output impedance 0 Ohm
- Rel. THD+N : -109dB with 300 Ohm Load
- Dyn Range: 124dB (A-weighted)
PRODUCT SIZE
- Weight: 2lbs. / 0.95 kg
- Dimensions: 8.85” x 7” x 3.54” / 22.5cm x 18cm x 9cm
