Specifications
RMS Stereo Power(8ohms):
1000W
RMS Stereo Power(4ohms):
1500W
Power(4ohms):
1500W/CH
Power(8ohms):
1000W/CH
Input Sensitivity:
0.775V/1V/32dB Switchable
S/N Ratio:
>105dB
Frequency Response:
20Hz-20kHz ±2dB
THD (@1kHz):
<0.1% @8Ω, 1kHz
IMD (@60Hz/7kHz 4:1):
<0.5% @8Ω, 60Hz/7kHz 4:1
Damping Factor:
>1000 @8Ω, 100Hz
Rated Power Supply:
220-230V ~ 50/60Hz
Amplifier Type:
Class D
Power Supply Specifications:
220-230V ~ 50/60Hz
Cooling:
Dual Cooling Fan Controlled by Temperature
Temperature:
Working temperature -10°C~40°C Storeage temperature -25°C~80°C
Input connector:
2 x XLR
Output Connector(link in):
2 x XLR
Output Connector(power):
2 x NL4
Rated Power Consumption:
5A
Dimension (W x D x H):
89 x 482 x 279mm / (3.5 x 19 x 11in)
Package Dimensions (W x D x H):
590 x 455 x 165mm / (23.2 x 17.9 x 6.5in)
Net Weight:
14 kg / 30.9 lb
Gross Weight:
16 kg / 35.3 lb
